Cyclone V based 6U cPCI COTS Module

Cyclone V based 6U cPCI COTS Module

iWave’s Cyclone V based 6U cPCI Card is a rugged standalone module complaint with 6U size CPCI PICMG 2.0 Rev 3.0 backplane, aimed for the high-speed data, video processing, and display applications. The card offer speed up to 512MB/s of DMA transfer and up to a 6 channels of transceiver interfaces capable of operating up to 6 Gbps, SFP, Built-in health monitoring circuits, DVI Input, and Output Interfaces

Category:

Specification

    • Reconfigurable Intel Cyclone V GT FPGA with 150K LEs
    • 16-Bit 512MB DDR3
    • FPGA Configuration: ASx4
    • Support for both Front Panel & BackPlane Interfaces
    • 6 pairs High-Speed Transceiver Channels Operating Speed up to 6 Gbps
    • Supported Interface:
      • 1 x DVI Transmitter
      • 2 x DVI Receiver
      • 1 x SFP+
    • Cooling Method: Conduction-Cooled
    • Operating Temperature : -40 °C to +85 °C
    • Storage Temperature : -55 °C to +105 °C
    •  P-Bit, I-Bit, C-Bit
    • Form Factor: 6U cPCI

HIGHLIGHTS

  • Reconfigurable Intel Cyclone V GT FPGA with 150K LEs
  • SFP Port for Fibre Channel
  • Support for both Front Panel & BackPlane
  • 6 pairs High-Speed Transceiver Channels Operating Speed up to 6 Gbps
  • 6U form factor cPCI MIL Grade
